| Decoding | Description |
| Decoding Format | Ultra 265, H.265, H.264 |
| Decoding Capability | NVR301‑04S3‑P4:1 x 4K@30, 4 x 5MP@25, 4 x 4MP@25, 4 x 3MP@25 NVR301‑08S3‑P8:1 x 4K@30, 4 x 5MP@25, 4 x 4MP @25, 4 x 3MP@25, 6 x 1080P@30, 8 x 720P@30 |
| AudioCompression | G.711A, G.711U |
| Network | Description |
| Incoming Bandwidth | 64Mpbs |
| Outgoing Bandwidth | 48Mpbs |
| Remote Users | 128 |
| Protocols | TCP/IP;P2P;UPnP;NTP;DHCP;PPPoE;HTTP;HTTPS;DNS;DDNS;SMTP;RTSP |
| Browser (plugin) | Windows:IE(IE10/11), Firefox (version 52.0 and above), Chrome(version 45 and above), Edge(version 79 and above) |
| Video/Audio Input | Description |
| IP Video Input | NVR301‑04S3‑P4:4‑ch NVR301‑08S3‑P8:8‑ch |
| Video/Audio Output | Description |
| HDMI Output | HDMI:4K(3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA Output | VGA:1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| RCAAudio Output | 1-ch |
| LiveviewDisplay | NVR301‑04S3‑P4:1/4 NVR301‑08S3‑P8:1/4/6/8/9 |
| CorridorModeScreen | NVR301‑04S3‑P4:3/4 NVR301‑08S3‑P8:3/4/5/7/9 |
| Snapshot | Description |
| FTP/Schedule/EventSnapshot | 1‑ch snapshot, up to D1 resolution |
| Smart | Description |
| VCADetectionbyIPC | Face Detection;SIP(Intrusion Detection, Cross Line Detection, Enter Area, Leave Area);Ultra Motion Detection(UMD) |
| VCAsearch | Behavior Search |
| SmartbyIPC | Total 4‑ch(Face Detection, SIP, UMD) |
| Alarm | Description |
| General Alarm | Auto Tracking;Motion Detection;Tampering;Human Body Detection;Video Loss;Alarm Input;Audio Detection |
| Alert Alarm | IP Conflict;Network Disconnected;Disk Offline;Disk Abnormal;Illegal Access;Hard Disk Space Low;Hard Disk Full;Recording/Snapshot Abnormal |
| GUI Language | Description |
| GUI Language | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian |
| Hard disk | Description |
| SATA | SATA 1 Interface |
| Capacity | Up to 10TB for each HDD(The maximum HDD capacity varies with environment temperature and hard disk size) |
| External Interface | Description |
| Network Interface | 1 RJ45 10M/100M self‑adaptive Ethernet Interface |
| USB | Rear panel: 2 x USB2.0 |
| RS485 | N/A |
| RS232 | N/A |
| Alarm In | N/A |
| Alarm Out | N/A |
| Power supply | NVR301‑04S3‑P4:DC 48V/1.35A NVR301‑08S3‑P8:DC 52V/1.8A |
| PoE | Description |
| Interface | 10M/100M self‑adaptive Ethernet Interface |
| Max Power | NVR301‑04S3‑P4:Max 30W for single port, Max 54W in total NVR301‑08S3‑P8:Max 30W for single port, Max 75W in total |
| Supportedstandard | IEEE 802.3at, IEEE 802.3af |
| Working Environment | Description |
| Working temperature | -10°C ~ 55°C (14°F ~ 131°F) |
| Working Humidity | ≤ 90% RH (non-condensing) |
| Power Consumption (without HDD) | ≤ 9W |
| Dimensions | Description |
| Weight(without HDD) | ≤ 1.1Kg (2.43lb) |
| Dimensions | 260mm × 240mm × 46mm (10.2″×9.4″×1.8″ |
| Certificate | Description |
| Certification | CE;FCC;UL;RoHS;WEEE |
| EC | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
| FCC | Part 15 Subpart B |
