| Camera | Description |
| Image sensor | 1/2.8″, progressive scan, 5.0 megapixel, CMOS |
| Minimum Illumination | Colour: 0.01 lux (F2.0, AGC ON) 0 lux with IR |
| Day/Night | IR-cut filter for day & night function |
| Shutter | Auto/Manual, shutter time: 1~1/100000 s |
| WDR | 120dB |
| S/N | >55dB |
| Lens | Description |
| Lens Type | 1.4mm@F2.0 |
| Iris | Fixed |
| Angle Of View | 360° |
| DORI Distance | Description |
| DORI Distance (Lens) | 1.4mm |
| DORI Distance (Detect) | 31.5 |
| DORI Distance (Observe) | 12.6 |
| DORI Distance (Recognize) | 6.3 |
| DORI Distance (Identify) | 3.2 |
| Illuminator | Description |
| IR Range | UP to 10m (33ft) |
| Wave length | 850nm |
| IR On/Off | Auto/Manual |
| Video | Description |
| Compressions | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Third Stream: D1 (720576), Max 30fps; 640360,Max 30fps; 2CIF(704288), Max 30fps; CIF(352288), Max 30fps; |
| Video Bit Rate | 128 Kbps~16 Mbps |
| U-Code | Support |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 Areas |
| ROI | Up to 8 Areas |
| Video Stream | Triple Streams |
| Image | Description |
| White balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Flip Vertical/ Flip Horizontal/180° |
| Dewarping | N/A |
| HLC | N/A |
| BLC | Support |
| Defog | Digital Defog |
| Events | Description |
| Statistical Analysis | heat map |
| Basic Detection | Motion detection, tampering alarm, audio detection |
| General Detection | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio | Description |
| Audio Compressions | G.711 |
| Audio Bit Rate | 64 Kpbs |
| Two Way Audio | Supported |
| Suppressions | Supported |
| Sampling Rate | 8 KHz |
| Storage | Description |
| Edge Storage | Micro SD, up to 256GB |
| Network Storage | ANR, NAS(NFS) |
| Network | Description |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSH |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API,SDK |
| User/Host | Up to 32 users. 2 user levels: administrator and common user |
| Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client | EZStation EZView EZLive |
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+ |
| Live View Display | Description |
| Mount Type | Support table, wall, and ceiling |
| Decoding Mode | Support software decoding |
| Display Mode | Wall mount: fisheye view, Panoramic, Panoramic+3PTZ, Panoramic+4PTZ, Panoramic+8PTZ Table mount: fisheye view, 360°Panoramic+1PTZ, 180°Panoramic, Fisheye+3PTZ, Fisheye+4PTZ, 360°Panoramic+6PTZ, Fisheye+8PTZ |
| Interface | Description |
| Audio I/O | Input: impedance 35 kΩ; amplitude 2 V [p-p] Output: impedance 600 Ω; amplitude 2 V [p-p] |
| Alarm I/O | 1/1 |
| RS485 | N/A |
| Built-in-Mic | Supported |
| Built-in-Speaker | N/A |
| WIFI | N/A |
| Network | 1 * RJ45 10M/100M Base-TX Auto-adaptive Ethernet |
| Video Output | N/A |
| Certifications | Description |
| EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
| Safety | CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
| General | Description |
| Power | DC12V±25%,PoE (IEEE 802.3af) Power consumption: Max. 8.5W |
| Power Interface | Ø 5.5mm coaxial power plug |
| Dimensions (Φ × H) | Φ125 × 43.7 mm (Φ4.9″ × 1.7″) |
| Weight | 0.36kg (0.79lb) |
| Material | Metal + Plastic |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge button | 4 KV |
| Reset Button | Supported |
