| Cable | Description |
| Product Model | CAB-LC3100B-IN |
| Text Standard | ISO/IEC11801 ED.2 ANSI/TIA-568-C.2 |
| Product Specification | Cat6. U/UTP. 4×2×0.57mm |
| Packing Length | 305±1m |
| Ambient temperature | -20℃～60℃ |
| Rip Cord | Yes |
| Crossing Backbone | Yes |
| Conductor | Description |
| AWG | 23 |
| Nom.O.D.(mm) | 0.57±0.005 mm |
| DC resistance | ≤95 Ω/km |
| Material | Solid-Bare Copper |
| Insulation | Description |
| Diameter | 1.02±0.05 mm |
| Material | HDPE |
| Thickness | 0.2±0.02 mm |
| Color | Blue/White- Blue,Green/White-Green,Orange/White-Orange,Brown/White-Brown |
| Pitch | Description |
| Off Set pitch | ≤20 mm |
| Cable Pitch | ≤120 mm |
| Sheath | Description |
| Material | PVC(complies RoHS/REAC) |
| Thickness | 0.6±0.05 mm |
| External O.D | 6.2±0.3 mm |
| Tensile strength | 13.5 Mpa |
| Color | Blue(RAL5015) |
| Surface Printing | Description |
| Color | Black |
| Letter Height | 420mm205mm420mm |
| Print error/Space | 450mm440mm445mm |
| Case Number | 2 Cases |
